How to Add a Default IP Address to a MikroTik Router

🧭 Setting up a MikroTik router for the first time? Start by assigning a default IP address to the device. This step is necessary so you can manage it. MikroTik routers are powerful, customizable, and ideal for home users and network professionals. Here’s a straightforward guide to get you started.

Steps to Add a Default IP Address

Note: These steps assume you’re using Winbox, MikroTik’s graphical management tool, or terminal access via SSH/console.

Using Winbox (Graphical Interface)

1. Connect to your MikroTik router
   • Use Winbox to connect via MAC address (useful if IP isn’t yet configured).
   • Login with the default username: admin (password is blank by default).
2. Go to IP > Addresses
   • On the left menu in Winbox, click IP, then select Addresses.
3. Click the “+” Button to Add a New Address
4. Enter the IP Address
   • In the “Address” field, type the desired IP with subnet mask (e.g., 192.168.88.1/24).
   • In the “Interface” dropdown, choose the interface (e.g., ether1 or bridge).
5. Click “Apply” then “OK”
   • Your default IP is now set, and the router can be accessed using it.
6. See the screenshot step-by-step

When you have logged in to Mikrotik from Winbox already, go to => IP => Address

1. Configure IP Address

2. Configure DHCP Server

Why Configure DHCP Server on MikroTik?

A DHCP (Dynamic Host Configuration Protocol) Server is essential for automating the process. It assigns IP addresses and network settings to devices in your network. You no longer need to manually set IP addresses on every device. The DHCP server makes sure each client gets a valid IP address. This includes devices like a phone, computer, or printer. It ensures all IP addresses are unique.

When you configure a DHCP Server on your MikroTik router, you simplify network management by:

• 🔄 Automating IP assignment – No need to manually configure each device.
• 🚫 Preventing IP conflicts – Ensures every connected device gets a unique IP address.
• 📡 Enabling plug-and-play networking – Devices can connect and get network access instantly.
• 🛠️ Easier troubleshooting and network scalability – Makes growing or maintaining a network smoother.

You might be setting up a home network, office LAN, or a hotspot system.

It is crucial to enable DHCP on your MikroTik router for these networks.

It ensures efficient and hassle-free network management.

Add the Default Gateway for the Default IP Address of Mikrotik

Here, you can exclude some IP addresses from your network.

For the DNS Server, you can add 8.8.8.8 or keep it optional. Because we just add default IP Address to the Mikrotik for default only. the

Set Release time, up to you

Now, you are successful with the configuration DHCP Server

Using Terminal (Command Line)

1. Connect via console or SSH, or open the terminal in Winbox.
2. Use the following command:/ip address add address=192.168.88.1/24 interface=ether1
   • Replace 192.168.88.1/24 with your desired network.
   • Replace ether1 with your actual interface name.
3. Verify with: /ip address print

To add an IP Address to the Mikrotik router via Command Line Interface (CLI), enter it as above.

Use this command: /ip address print to check your configuration. And go to check from Interface as below.

Now that you’ve added a default IP address, you can manage your MikroTik router with ease. You can continue with other configurations like DHCP, NAT, or firewall rules. MikroTik’s routers are reliable and feature-rich, making them an excellent investment for robust networking.

📦 Tip: You can buy MikroTik routers and accessories conveniently from Amazon. Go to “MikroTik router” to explore models that suit your needs!

Product Review: MikroTik cAP ac

The MikroTik cAP ac is a dual-band wireless access point designed for indoor use. It is particularly ideal for ceiling-mounted installations. It is suitable for various environments, such as offices, schools, and public spaces. The cAP ac is manufactured by MikroTik. This company is a well-known provider of networking equipment. The device aims to deliver reliable wireless connectivity using the 802.11ac standard. This product is well-suited for users looking for high-performance Wi-Fi solutions with flexible deployment options.

Appearance and Design

The MikroTik cAP ac features a sleek and minimalistic design. This design allows it to blend seamlessly with any ceiling or wall. The device is finished in a clean white color, which is typical for commercial access points. Its compact size measures approximately 22 x 22 cm. Its low profile makes it unobtrusive. This allows it to fit well in both modern and traditional settings.

One unique design feature is its ability to be mounted on the ceiling or wall, providing flexibility in installation. The cAP ac comes with a sturdy enclosure. It not only protects the internal components but also ensures durability in various environments.

Key Features and Specifications

• Dual-band support: Operates on both 2.4GHz and 5GHz frequencies.
• Wireless Standard: 802.11ac, providing fast wireless speeds and improved performance.
• Factory Locked Frequencies: 2412-2462MHz (2.4GHz) and 5170-5250MHz / 5725-5835MHz (5GHz).
• Mounting Options: Designed for ceiling or wall installation.
• Ports: Two Gigabit Ethernet ports, with one supporting Power over Ethernet (PoE) output.
• Advanced Configuration: Supports MikroTik RouterOS for extensive customization and management options.

User Experience

In various scenarios, the MikroTik cAP ac has proven to be reliable and efficient. In a home office setup, it delivered consistent and fast Wi-Fi speeds. It easily handled multiple devices streaming video. It also conducted video calls and facilitated browsing the internet simultaneously without noticeable lag. In larger office spaces, the dual-band functionality provided ample coverage, minimizing dead zones and ensuring all users had stable connectivity.

The installation process was straightforward, thanks to the well-documented guidelines provided by MikroTik. The device could be mounted on either walls or ceilings. This feature allowed for optimal placement based on the layout of the space. Moreover, the RouterOS software allowed for easy customization, including setting up guest networks and managing bandwidth.

Pros and Cons

Pros

• High-speed dual-band connectivity with 802.11ac.
• Flexible mounting options for different environments.
• Diverse configuration options through MikroTik RouterOS.
• Durable build quality with a minimal aesthetic.

Cons

• Factory-locked frequencies may limit some users in specific regions.
• Requires some networking knowledge for optimal configuration.
• Not the most user-friendly for beginners lacking technical experience.

Conclusion

1

MikroTik cAP ac Dual-band 802.11ac Wireless Access Point (RBcAPGi-5acD2nD-US)

8.8

BUY NOW

Amazon.com

The MikroTik cAP ac Dual-band Wireless Access Point (RBcAPGi-5acD2nD-US) is an excellent choice. It is ideal for users seeking a reliable and high-performance wireless solution. Its compact design makes it suitable for various settings. The dual-band capabilities and extensive configuration options allow usage from home offices to larger commercial spaces.

The factory-locked frequencies may be drawbacks for certain users. Some technical expertise might be needed as well. However, the advantages in terms of performance and flexibility greatly outweigh these cons. If you invest the time to configure, you will have exceptional wireless connectivity with the MikroTik cAP ac. This device meets diverse networking needs.
