How to Log In to MikroTik Router via SSH

Secure Shell (SSH) is a powerful way to log into your MikroTik router’s command-line interface over a secure, encrypted connection. It’s especially useful for remote management and automation.

Step-by-Step Guide

Whether you’re using Windows, macOS, or Linux, connecting via SSH is simple. Ensure your MikroTik router is properly configured for logging in.

Step 1: Enable SSH on the Router

By default, SSH is enabled on MikroTik devices, but it’s good to verify.

• Open Winbox or WebFig.
• Navigate to IP > Services.
• Ensure that SSH (Port 22) is enabled and not blocked by firewall rules.
• Optional: Restrict SSH access by IP or interface for security.

SSH (Port 22) is enabled

Log in to MikroTik router with SSH by enabling the necessary ports. There are more services that you can allow or disable those ports.

Step 2: Identify Router’s IP Address

• You need the router’s public IP, local IP, or hostname to connect.
• You can find this in IP > Addresses in Winbox/WebFig.

Here, I am testing with the Mikrotik Default IP Address 192.168.88.1, which is necessary for logging in.

Step 3: Use an SSH Client

On Windows: Using PuTTY

1. Download and install PuTTY.
2. Open PuTTY.
3. In the Host Name (or IP address) field, enter the router’s IP to log in.
4. Set Port to 22 and Connection type to SSH.
5. Click Open.
6. When prompted, enter your MikroTik username and password.

After you have downloaded the putty application and double click on it

Enter your Mikrotik IP Address: 192.168.88.1, Port: 22, Select SSH, and you can save or not, up to you. And below, you use Always or Only on clean exit, then click Open

When logging in for the first time, it alerts like this, just click on Accept. Then it will log in to the Mikrotik that you need to enter the Username and Password as admin. Now I don’t set up a username and password login because example by default.

Now, you can log in to Mikrotik router successfully. It is the CLI terminal, completing the Log In MikroTik Router with SSH process.

On macOS/Linux: Using Terminal

If you use macOS or Linux, please follow with below step

1. Open the Terminal, a key component to log in MikroTik router with SSH.
2. Type the following command: ssh admin@192.168.88.1 Replace admin with your username and 192.168.88.1 with your router’s IP.
3. Enter your password when prompted.

Step 4: You Are Now Logged In

• Once logged in, you’ll see the MikroTik CLI prompt.
• From here, you can run configuration commands, monitor traffic, and more.

Accessing your MikroTik router via SSH gives you secure and direct control over your network device. It is ideal for both remote administration and script-based configuration. Always use strong passwords and restrict SSH access where possible to maintain security. With just a few steps, you’re connected and in full command of your MikroTik router after logging in with SSH.

Mikrotik RouterBOARD cAP-2nD PoE Review

The Mikrotik RouterBOARD cAP-2nD is a ceiling-mounted access point designed by MikroTik, a well-known manufacturer in the networking equipment sector. This product is a type of wireless access point. It is intended mainly for use in environments such as hotels, airports, and shopping malls. These are places where seamless Wi-Fi coverage is essential. With its unobtrusive design and robust functionality, the cAP-2nD aims to provide reliable connectivity while blending into its surroundings.

Product Appearance and Design

The cAP-2nD features a sleek and minimalist design that allows it to blend seamlessly into a variety of settings. Constructed with durable materials, it showcases a modern aesthetic that is suitable for both commercial and residential installations. The ceiling-mount design eliminates clutter. It maximizes space efficiency. This makes it an ideal choice for venues where aesthetics are as important as functionality. Its all-white finish provides a discreet look, ensuring that it does not detract from the decor of the environment.

Key Features and Specifications

• Frequency Band: 2.4GHz
• Dual-Chain Technology for improved performance
• Support for 802.11b/g/n wireless standards
• Power over Ethernet (PoE) capability for simplified installation
• Compatibility with MikroTik CAPsMAN for centralized control
• Includes wall/ceiling mount, PoE injector, power adapter, screws, and anchors

Experience Using the Product

In real-world scenarios, the cAP-2nD has received mixed feedback from users. Users have noted that the access point functions effectively for standard networking needs in instances where it has been deployed. This is especially true in bars or restaurants. The ability to handle multiple SSIDs and VLANs makes it suitable for establishments requiring separate networks for guests and staff. Users have reported satisfactory coverage within interior spaces. Some noted that the signal may weaken outdoors. This aligns with typical performance expectations for 2.4GHz devices.

Some users expressed concerns about the product’s pricing. They were worried about its cost relative to its age and features. This indicates that it may not offer the best value for money. Additionally, setup using the CAPsMAN has been praised for its ease of use. It does require a certain level of networking knowledge to configure effectively. One user highlighted a potential issue with the LAN port negotiation. This issue limits functionality under certain conditions. It could deter less tech-savvy buyers.

Pros and Cons

Pros:

• Seamless integration into various environments due to its design.
• Robust performance and support for multiple SSIDs and VLANs.
• Centralized management through CAPsMAN without needing a separate controller.
• Includes all necessary components for installation.

Cons:

• May be considered overpriced for its age and lack of advanced features compared to newer models.
• Requires some networking knowledge for proper setup and configuration.
• Potential LAN port negotiation issues reported by users.

Conclusion

The Mikrotik RouterBOARD cAP-2nD is a capable ceiling access point. It excels in environments where aesthetic considerations are important. Reliable performance is also crucial. It has some limitations, especially with its pricing and setup complexity. However, it remains a robust option for users familiar with MikroTik equipment.

The cAP-2nD may be a fitting choice for those seeking a straightforward access point. It offers good coverage. It also provides centralized management capabilities. However, prospective buyers should weigh its features against their specific needs and budget before making a decision.
