How to Manage Bandwidth on a MikroTik Router

To effectively manage bandwidth on a MikroTik Router, it is crucial to maintain a fast, stable, and fair network. This is especially important in environments where multiple users or devices share a single internet connection. MikroTik routers offer robust tools in RouterOS to monitor, limit, and shape traffic using queues.

Step: Manage Bandwidth MikroTik

Whether you’re an ISP, office administrator, or home user, this guide will assist you effectively. It will help you manage the bandwidth on a MikroTik Router efficiently. It will guide you through the allocation process step by step.

✅ Step 1: Identify Interface IP Ranges

Before applying bandwidth limits:

• Know your WAN interface (e.g., ether1, pppoe-out1)
• Know your LAN IP range (e.g., 192.168.88.0/24)

✅ Step 2: Use Simple Queues

(Basic Bandwidth Limiting). Example: Limit a single device (IP: 192.168.88.10) to 5 Mbps download and 2 Mbps upload.

/queue simple add name="Limit_User1" target=192.168.88.10/32 \
 max-limit=5M/2M comment="Limit for User1"

Tip: Use Winbox to add Simple Queues via Queues > Simple Queues.

✅ Step 3: Use Per Connection Queuing

We Use PCQ For Fair Bandwidth Sharing. To share bandwidth fairly among multiple users, set up PCQ (Per Connection Queueing).

Step 3.1: Create PCQ Queue Types

/queue type
add name=pcq-download kind=pcq pcq-classifier=dst-address pcq-rate=5M pcq-total-limit=2000000
add name=pcq-upload kind=pcq pcq-classifier=src-address pcq-rate=2M pcq-total-limit=2000000

Step 3.2: Create a Simple Queue Using PCQ

/queue simple add name="LAN Bandwidth Limit" target=192.168.88.0/24 \
 queue=pcq-upload/pcq-download max-limit=10M/10M

This evenly distributes the 10 Mbps connection among all users in the subnet.

✅ Step 4: Use Queue Trees

We use the Queue Trees for Advanced Bandwidth Management (Optional). Queue Trees are better for upload/download separation and multiple bandwidth classes on your MikroTik Router.

Step 4.1: Mark Traffic in Mangle

/ip firewall mangle
add chain=forward src-address=192.168.88.0/24 action=mark-packet new-packet-mark=upload passthrough=yes
add chain=forward dst-address=192.168.88.0/24 action=mark-packet new-packet-mark=download passthrough=yes

Step 4.2: Create Queue Tree Rules

/queue tree
add name="Upload Limit" parent=ether1 packet-mark=upload queue=pcq-upload max-limit=10M
add name="Download Limit" parent=ether1 packet-mark=download queue=pcq-download max-limit=10M

Replace ether1 with the correct interface (LAN or WAN, depending on direction).

✅ Step 5: Monitor Bandwidth Usage

• Use Winbox > Queues to see real-time usage.
• Use Tools > Torch to inspect live traffic per IP, port, and protocol.

✅ Step 6: Prioritize Critical Services

This step is (Optional). You can use priority settings in queues to ensure services like VoIP or Zoom get better bandwidth quality.

Example:

/queue simple add name="VoIP Priority" target=192.168.88.50/32 \
 max-limit=1M/1M priority=1

Managing bandwidth on a MikroTik router is both flexible and powerful. You might want a simple per-user limit. Alternatively, you could seek advanced control using queue trees and packet marking. MikroTik gives you all the tools you need to effectively manage your bandwidth.

Start with simple queues if you’re new, and move into PCQ or queue trees as your network grows in complexity. With proper bandwidth management, you’ll enjoy a smoother and more reliable internet experience for everyone on your network.
