Processing of NAT translation between Private and Public IP

Here’s a detailed explanation of how NAT (Network Address Translation) works. It processes the translation between private and public IP addresses.

NAT Translation Process: Private to Public IP

This includes a step-by-step transformation of the data packet. The explanation also shows how routers handle this communication. Visit the diagram of NAT from Private IP to Public IP.

Scenario:

• A device on a private network (e.g., 192.168.1.100) wants to access a website on the internet (e.g., www.example.com with IP 93.184.216.34).
• The router has a public IP address (e.g., 203.0.113.5).

Step: NAT Translation (Outbound Request)

1. Device Sends a Request

• Source IP: 192.168.1.100 (Private IP of device)
• Destination IP: 93.184.216.34 (Public IP of website)
• Source Port: e.g., 45000
• Destination Port: 80 (HTTP)

Packet Before NAT (LAN side):

SRC IP: 192.168.1.100:45000
DST IP: 93.184.216.34:80

2. Router Performs NAT Translation

• The router looks at its NAT table or creates a new entry.
• It replaces the source IP and port with its public IP and a unique port number (e.g., 203.0.113.5:62001).

Packet After NAT (WAN side):

SRC IP: 203.0.113.5:62001
DST IP: 93.184.216.34:80

➡ NAT Table Entry Created:

192.168.1.100:45000 → 203.0.113.5:62001

Step: NAT Translation (Inbound Response)

3. Web Server Sends a Reply

• The server responds to 203.0.113.5:62001

Packet Received on Router:

SRC IP: 93.184.216.34:80
DST IP: 203.0.113.5:62001

4. Router Looks Up NAT Table

• Router checks the destination port (62001) and finds the corresponding internal IP and port.

➡ NAT Table Lookup:

203.0.113.5:62001 → 192.168.1.100:45000

5. Router Rewrites the Packet

• The router changes the destination IP and port back to the internal device’s IP and source port.

Final Packet Delivered to LAN:

SRC IP: 93.184.216.34:80
DST IP: 192.168.1.100:45000

Summary of the NAT Process:

NAT translation is a seamless process. It allows private devices to communicate with the public internet by rewriting IP addresses. It also modifies port information in real time. The router maintains a NAT table to track active connections and correctly routes return traffic. Whether using MikroTik, Cisco, or any other router, this translation process ensures efficient and secure use of public IP resources.

You can also see the diagram or example commands for MikroTik or Cisco routers showing this process. Whether using MikroTik, Cisco, or any other router, this translation process ensures efficient and secure use of public IP resources. You can also see the diagram or example commands for MikroTik or Cisco routers showing this process.
