MikroTik routers are known for their flexibility and advanced networking features. One of the core concepts in managing any router is understanding the difference between physical interfaces and virtual interfaces. This understanding of Physical vs Virtual Interfaces is critical for building and managing robust networks. However, they serve very different purposes. Knowing how they work will help you configure your router more effectively for various network designs and services.
Table of Contents
Physical Interfaces
Definition:
Physical interfaces are the actual hardware ports on the MikroTik router. These include Ethernet ports, fiber ports (SFP), and wireless radios.
Examples of Physical Interfaces:
ether1,ether2,ether3(standard Ethernet ports)sfp1(fiber port)wlan1(built-in wireless interface)
Functions:
- Connects directly to other physical devices (switches, PCs, ISPs)
- Transmits and receives data packets physically
- Used for WAN (internet), LAN, and direct hardware-level communication
Key Characteristics:
- Cannot be deleted
- Tied to hardware
- Requires cable or wireless connection
Virtual Interfaces
Definition:
Virtual interfaces are software-based interfaces that exist within the router’s operating system (RouterOS). Understanding Physical vs Virtual Interfaces helps to explore how they don’t correspond to a physical port. Instead, they are used to create logical connections for routing. They are also used for tunneling, VLANs, bridges, and more.
Examples of Virtual Interfaces:
- Bridge:
bridge1(aggregates multiple interfaces into one logical interface) - VLAN:
vlan10(used for network segmentation) - PPP/PPPoE:
pppoe-out1(for authenticated WAN connections) - Tunnel Interfaces:
gre1,ipip1,l2tp1 - Loopback Interface: Used for testing and internal routing
Functions:
- Create virtual network segments (e.g., VLANs)
- Enable advanced services like VPNs and tunnels
- Aggregate or manage traffic logically (e.g., bridges, bonding)
Key Characteristics:
- Created and removed in software
- Flexible and customizable
- May rely on one or more physical interfaces underneath
Comparison Table:
| Feature | Physical Interface | Virtual Interface |
|---|---|---|
| Based on Hardware | Yes | No |
| Can Be Created/Deleted | No | Yes |
| Example Names | ether1, wlan1, sfp1 | bridge1, vlan10, pppoe-out1 |
| Function | Physical connection to network | Logical/virtual function or segmentation |
| Depends on Physical HW | Yes | May or may not |
| Common Uses | WAN, LAN links, Wi-Fi | VLANs, PPPoE, tunnels, bridges, loopbacks |
Understanding the distinction between physical and virtual interfaces in MikroTik is essential for designing efficient and secure networks. Physical vs virtual interfaces explains that physical interfaces are the actual hardware ports used for connecting devices. Virtual interfaces provide flexibility for advanced configurations, including VLANs, VPNs, and bridging. Together, they give MikroTik its powerful ability to adapt to various networking environments—from simple home setups to complex enterprise typologies.
